econogrid

econogrid is suitable for any suspended ceiling application including offices, retail outlets, hospitals, schools, hotels and restaurants. The sections have a 24mm white capped face and a 38mm stalk for fixing the grid.

Features and benefits include:-

  • high quality hot-dip galvanised steel with a pre-painted capping which ensures effectiveness against corrosion
  • positive lock coupling with an audible click
  • re-usable
  • stepped end cross tees that prevent tee rotation
  • mid-span deflection not exceeding 1/360 of the span length
The main tee specifically has a fire safety feature and are punched at 100 centres to facilitate versatility.

Product List

Product Information

4653 in stockR83.52 Each
CGDMTW36

Length: 3600

Colour / Edge Detail: White

Type: 38 x 24mm

Stocking UOM: EA

Mass per Stocking UOM (kg): 1.21

Qty Per Carton: 30

Technical Information

Fire Classification: Includes Fire Safety Feature

Product Information

21376 in stockR25.56 Each
CGDCTW12

Length: 1200

Colour / Edge Detail: White

Type: 38 x 24mm

Stocking UOM: EA

Mass per Stocking UOM (kg): 0.34

Qty Per Carton: 60

Product Information

8850 in stockR12.78 Each
CGDCTW07

Length: 600

Colour / Edge Detail: White

Type: 38 x 24mm

Stocking UOM: EA

Mass per Stocking UOM (kg): 0.17

Qty Per Carton: 60

Product Information

2082 in stockR54.43 Each
CGDWAW36

Length: 3600

Colour / Edge Detail: White

Type: 22 x 22mm

Stocking UOM: EA

Mass per Stocking UOM (kg): 0.64

Qty Per Carton: 40

Product Information

1519 in stockR76.64 Each
CGDZ1S36

Length: 3600

Colour / Edge Detail: White

Type: 25 x 22 x 22 x 13mm

Stocking UOM: EA

Mass per Stocking UOM (kg): 1.76

Qty Per Carton: 40

Product Information

1810 in stockR83.52 Each
CGCMTB36

Length: 3600

Colour / Edge Detail: Black

Stocking UOM: EA

Mass per Stocking UOM (kg): 1.21

Qty Per Carton: 30

Technical Information

Other: 24 x 38mm

Product Information

10134 in stockR25.56 Each
CGCCTB12

Length: 1200

Colour / Edge Detail: Black

Stocking UOM: EA

Mass per Stocking UOM (kg): 0.34

Qty Per Carton: 60

Technical Information

Other: 24 x 38mm

Product Information

6522 in stockR12.78 Each
CGCCTB07

Length: 600

Colour / Edge Detail: Black

Stocking UOM: EA

Mass per Stocking UOM (kg): 0.17

Qty Per Carton: 60

Technical Information

Other: 24 x 38mm

Product Information

1021 in stockR54.43 Each
CGCWAB36

Length: 3600

Colour / Edge Detail: Black

Stocking UOM: EA

Mass per Stocking UOM (kg): 0.64

Qty Per Carton: 40

Technical Information

Other: 22 x 22mm

Product Information

891 in stockR76.64 Each
CGCZ1S36

Length: 3600

Colour / Edge Detail: Black

Stocking UOM: EA

Mass per Stocking UOM (kg): 0.76

Qty Per Carton: 40

Technical Information

Other: 25 x 22 x 22 x 13mm
